Series

Specification

Air consumption
[l/min(ANR)]

Suction Flow [l/min(ANR)]

Maximum vacuum pressure
[kPa]　　　

13～385

6～350

-57.2/-86.7/-91.8

13～180

6～136

-46.6/-57.2/-86.7/-91.8

9.5～28

5.5～21

-57.2/-91.8

9.5～28

5.5～21

-57.2/-91.8

13～44

5.5～38

-57.2/-86.7/-87.8/-90.4

9.7～21

7～18.5

-57.2/-91.8

13～100

6～95

-57.2/-86.7/-90.6/-91.8

13～180

6～165

-57.2/-86.7/-90.6/-91.8

13～180

6～136

-46.6/-57.2/-86.7/

-90.6/-91.8

9.5～28

5.5～21

-57.2/-91.8

13～100

6～95

-57.2/-86.7/-90.6/-91.8

9～44

6～26

-53.3/-86.6

9～75

6～36

-57.2/-90.6

Series

Pad diameter [mm]

Features

2～200

・Standard type
・Suitable for flat workpieces on suction surface

6～80

・2.5 Layer bellows pad
・Suitable for tilted or rounded on suction surface

10～200

・Gooseneck pad
・Suitable for tilting workpieces on suction surface
　due to ball joint construction

10～90

・3.5 Layer bellows pad
・Suitable for rod styple, rounded or tilted on suction surface,
　and shock absorptive in suction

10～50

・Fixing screw combined
・Compact,light weight,easy installation

2～200

・Spring built-in type
・Smooth movement by adoption of dry bearing

2～200

・ANA goose neck type
・Suitable for tilting workpieces on suction surface
　due to ball joint construction

Series

Name

Features

・Model selectable by vacuum flow
・Dirt and dust in the filter acknowledeable at a glance

・Silencer reducing exhaust sound of Ejector
・Some kinds of silencer available complying
　with Ejector's capacity

・Mini cylinder with cylinder diameter of 4.5～10mm
・Push action type & Pull action type & Double action type

・Digital setting with cubic types available and
　trimmer setting with thin types also available
・Compound pressure type also available to
　measure both negative/positive pressure
　in addition to analog output
